SAPSONS Extra Heavy Duty Slugging / Striking Wrenches are designed for use with hammers where impact or shock loading is required for loosening of frozen and rusty nuts and bolts. These slugging wrenches are duly forged from superior grade special alloy steel. The blanks are duly machined with the wrench openings broached to close tolerance as per federal specifications and undergo a heat treatment process including stress relieving before undergoing short blasting and surface finish operations. SAPSONS Slugging Wrenches are guaranteed for superior performance and durability. Slugging Wrenches are available in – RING PROFILE- Straight Flat , Box type & Offset Handle, OPEN JAW PROFILE– straight Flat and Offset handle , STRUCTURAL WRENCHES – Both Tapered Handle and Tubular Handle types CASTELLED WRENCHES or any special profiles to suit customer’s specific requirements. SAPSONS Slugging Wrenches are available in a range of sizes from 22 mm to 230 mm (7/8" to 9.1/8") across flat. These are suitable for most rigid applications and are useful for fertiliser plants, refineries, petrochemicals, heavy engineering industries, railways, iron and steel manufacturing plants, thermal power stations, etc. Features: * One Piece Forged Construction * Extra Heavy Duty High Impact Resistant * Greater Head Deptt. * Guaranteed Against Premature Failure * Large Striking Face

SAPSONS Hydraulic Cylinders are recognized for its high quality and standard. Our Large and Small Hydraulic Cylinders find various applications in different industries. Available in Single acting with Spring Return, Load Return, Flat Jacks, Low Profile, and Double Acting, Center Hole, Spring Return, Pull, Aluminum Cylinders. We also offer Custom built Hydraulic Cylinders as per the specification and application of our customer.

FEATURES & APPLICATIONS : • Used to cut conductors up to 40 MM DIA • Operation similar to a hydraulic jack • Knob-handle is turned to enable lineman to operate pump handle • When cut is completed, knob is turned in opposite direction to allow cutting head to open • Epoxiglass pole, handle and hydraulic hose have been tested upto 700 bar working pressure. • Hydraulic oil grade 68 is used in Hand pump. • Hose has a minimum burst strength of 15,000 PSI • Features include jaws designed to cut without flattening conductor. • Jaws are made out of special alloy steel for long and trouble free application • Well balanced, requiring minimum effort to cut large conductors.

Under Tube-End Facing / Chamfering Machines, replace text with: Sapsons SFM series tube end facing / chamfering machines are powerful yet portable machines designed to self-align and mount on tubes for fast tube-end facing and chamfering in constrained spaces. These are ideal for trimming condenser, chiller, and heat exchanger tubes to a specific tube projection after expansion. Salient Features - Light, portable, modular and ergonomic design - User-friendly experience due to quick interchangability of pilot - Range of tool bits available for tube-end facing, bevelling (internal and external) and weld seam machining - Available in electric, hydraulic and pneumatic drives - Saves money and inventory space, owing to a wide tube size range covered by a single machine Tube Size: 1½" - 7" (38.1 - 177.8 mm) OD

Tool Heads is fitted to the Flexible shaft to remove scale and hard deposits from inside the tubes of Processing Equipment. Available in Fixed type with Three and Spring type with 15 Sharp revolving Cutters, it chip the scale at high speed and the resultant centrifugal force. All parts are manufactured from special Alloy steel and heat treated for longer life. For Medium Size Straight Tubes: * PAD Type Arrowhead Drill For Opening Blocked Tubes * PBT Type Boring Tool For Cleaning Semi blocked * PSL Type Spring Loaded For Hard And Obstinate Scale * PDH Type Double Head For Hard And Medium Scale * PAD/UJ Type Drill Head With Universal Joint For Thick Scale * PPA Type Pivoted Arm For Uneven Hard Scale * PSF Type Swing Frame For All Types Of Scale * PSH Type Single Head For Hard And Medium Scale * WBA Type Cup Shaped For Scouring Of Thin Hard Scale * PTH Type Turk's Head For Scouring After Descaling * PDS Type Double Spiral For Scouring Carbon Scale * PGP Type General Purpose For Debarring Polishing Etc.

Flaring of projected tube ends, after Expansion ensures better grip of the tube with the Tube sheet. It can be used either manually or with Pneumatic Chipping Hammer. Made out of Special Alloy and heat treated , to withstand the impact load, while using. Handle portion is knurled for better grip. Available For Any Tube Size Between ½” To 1.1/2” OD Tubes

Salient Features: - Sturdy pillar (H frame/C frame type) - Standard or custom design that suits various needs and a wide range of applications - Superior quality electrical and hydraulic components used - Programmable logic control circuits can be provided on request - Special decompression and bumping circuits to extend service life - Structure qualifies standard acceptance tests - Designed to withstand higher overloads - Actuators/cylinders used are made of tubes & seals of international standards - Low maintenance - 2-400 ton pressing capacities - Comes with a manual for operating electrical controls Applications - Deep draw, crimping, punching, bending and straightening - Coining, compacting and sintering - Concrete paver block and tile manufacturing - Rubber moulding and Bakelite mounting and briquetting - Wax, malt coffee and juice extraction - Scrap bailing "

Hydraulic Bearing Pullers : Hydraulic Bearing Pullers are specialized tools designed to safely and efficiently remove bearings, gears, pulleys, and other press-fitted parts from shafts or housings without causing damage to the components or machinery.

SAPSONS Double-Ended Ratchet Spanner with Hex / Bi-Hex drive at both ends is a very useful tool for productivity. Used for loosening & tightening of bolts / nuts without detaching / resetting the tool, due to its in-built Ratcheting mechanism, these tools helps to reduce the operator fatigue and increase the comfort. The range covers across flat sizes 8 mm to 24 mm and 5/16″ to 1″. We also manufacture Single End Heavy duty Female Hex, Bi-Hex and Square Drive RATCHET WRENCHES with the A/F sizes of upto 3” with long Handle for the maintenance of Turbines, Ships, and for various applications. Very Useful in general engineering industry, automobile Industries , Thermal, Gas and Hydel Power plants and mass production and servicing industries. Special Sizes as per customer requirement can be also made on request.
