The SAPSONS ‘HJ’ Series Hydraulic Crimping Tools are heavy-duty hydraulic tools designed for crimping copper and aluminium cable terminal ends. They are manufactured from solid special alloy steel and are intended primarily for industrial/manufacturing environments where tool weight is less critical and crane handling facilities are available.
Construction and Working:
The Crimping Jack and Hydraulic Pump are connected with 2 Mtrs. long Hydraulic Hose pipe and the Hydraulic Hand pump is designed to develop Pressure of up to 250 Kg/ Sq.mm. The mechanism within the pump controls the pressure developed; while crimping and safety valve prevents overloading.
Key Features :
• Heavy-duty, robust construction using special alloy steel.
• Economy-model design with a sturdy/heavy construction.
• Suitable for crimping Copper and Aluminium cable terminal ends.
• Crimping capacity up to 400 sq. mm.
• Uses interchangeable Ring or Hex dies.
• Crimping jack and hydraulic hand pump are connected by a 2-metre hydraulic hose.
• Hydraulic hand pump develops pressure of up to 250 kg/sq. mm as specified by SAPSONS.
• Built-in hydraulic mechanism controls the developed pressure.
• Safety valve helps prevent overloading during operation.
Working Principle :
The HJ Series operates through a separate hydraulic hand pump and crimping jack. When the pump is operated, hydraulic pressure is transmitted through the 2-metre hose to the crimping head. The hydraulic force drives the selected die to compress the cable terminal onto the conductor, producing a secure mechanical and electrical connection. The pressure-control mechanism and safety valve help regulate operation and protect the system against excessive pressure.
Typical Applications - The HJ Series is particularly suited to:
• Electrical cable termination
• Industrial cable assembly
• Manufacturing plants
• Heavy-duty cable crimping operations
• Copper and aluminium lug/terminal crimping
• Applications where a robust, stationary or crane-assisted tool is acceptable
Parameter SAPSONS HJ Series
Tool Type : Hydraulic Crimping Tool
Construction : Solid Special Alloy Steel
Application : Copper & Aluminium Cable Terminals
Maximum Crimping Size : Up to 400 sq. mm
Die Type : Ring / Hex
Hydraulic Hose : 2 metres
Pump Type : Hydraulic Hand Pump
Maximum Stated Pressure : Up to 250 kg/sq. mm
Design : Heavy-duty / Economy
Primary Environment : Manufacturing & Industrial Plants
‘HJ’ Series : Hydraulic Crimping Tools are made out of Solid Special Alloy Steel, where weight is not an issue to the customer, and it is mainly used in manufacturing plants, with Crane facility. These tools are Economy model but heavy in design.
HJ Series Hydraulic Crimping Tools are available for crimping Copper and Aluminium Cable terminal ends up to 400 Sq.mm with Ring or Hex dies.
In short: The SAPSONS HJ Series is a rugged, economical, heavy-duty hydraulic crimping solution up to 400 sq. mm, best suited for industrial environments where durability and high crimping force are more important than low weight or portability.
Construction and Working:
The Crimping Jack and Hydraulic Pump are connected with 2 Mtrs. long Hydraulic Hose pipe and the Hydraulic Hand pump is designed to develop Pressure of up to 250 Kg/ Sq.mm. The mechanism within the pump controls the pressure developed; while crimping and safety valve prevents overloading.
Key Features :
• Heavy-duty, robust construction using special alloy steel.
• Economy-model design with a sturdy/heavy construction.
• Suitable for crimping Copper and Aluminium cable terminal ends.
• Crimping capacity up to 400 sq. mm.
• Uses interchangeable Ring or Hex dies.
• Crimping jack and hydraulic hand pump are connected by a 2-metre hydraulic hose.
• Hydraulic hand pump develops pressure of up to 250 kg/sq. mm as specified by SAPSONS.
• Built-in hydraulic mechanism controls the developed pressure.
• Safety valve helps prevent overloading during operation.
Working Principle :
The HJ Series operates through a separate hydraulic hand pump and crimping jack. When the pump is operated, hydraulic pressure is transmitted through the 2-metre hose to the crimping head. The hydraulic force drives the selected die to compress the cable terminal onto the conductor, producing a secure mechanical and electrical connection. The pressure-control mechanism and safety valve help regulate operation and protect the system against excessive pressure.
Typical Applications - The HJ Series is particularly suited to:
• Electrical cable termination
• Industrial cable assembly
• Manufacturing plants
• Heavy-duty cable crimping operations
• Copper and aluminium lug/terminal crimping
• Applications where a robust, stationary or crane-assisted tool is acceptable
Parameter SAPSONS HJ Series
Tool Type : Hydraulic Crimping Tool
Construction : Solid Special Alloy Steel
Application : Copper & Aluminium Cable Terminals
Maximum Crimping Size : Up to 400 sq. mm
Die Type : Ring / Hex
Hydraulic Hose : 2 metres
Pump Type : Hydraulic Hand Pump
Maximum Stated Pressure : Up to 250 kg/sq. mm
Design : Heavy-duty / Economy
Primary Environment : Manufacturing & Industrial Plants
‘HJ’ Series : Hydraulic Crimping Tools are made out of Solid Special Alloy Steel, where weight is not an issue to the customer, and it is mainly used in manufacturing plants, with Crane facility. These tools are Economy model but heavy in design.
HJ Series Hydraulic Crimping Tools are available for crimping Copper and Aluminium Cable terminal ends up to 400 Sq.mm with Ring or Hex dies.
In short: The SAPSONS HJ Series is a rugged, economical, heavy-duty hydraulic crimping solution up to 400 sq. mm, best suited for industrial environments where durability and high crimping force are more important than low weight or portability.
