"NW" Series Grooving Tools
Technical Specification
Tool No. | Tube Sheet Hole Diameter | Maximum Groove Depth | Adjustable Range (Face to Groove) | Shank Size (Morse Taper) |
1SNW2MT | 9.0 - 32.0 | 2.00 | 3.0 - 9.6 | 2 |
3SNW3MT | 16.0 - 45.0 | 3.50 | 3.0 - 14.0 | 3 |
4SNW4MT | 19.0 - 48.0 | 4.50 | 3.0 - 14.0 | 4 |
6SNW5MT | 38.0 - 114.0 | 7.60 | 3.0 - 16.0 | 5 |
