Tube Plug are specialized tools used primarily in industries such as power generation, petrochemical, and HVAC for the installation or removal of tube plugs in heat exchangers, condensers, boilers, or chillers. Tube plugs are used to seal off damaged or leaking tubes to prevent system contamination or performance degradation. Sizes: 3/8' to 1.1/2' (9.5 - 38.10 mm) OD

Air Drills: An air drill (also called a pneumatic drill) is a powerful drilling tool powered by compressed air instead of electricity. It’s commonly used in industrial, automotive, and manufacturing settings where durability and continuous use are important. Sizes: Available with 1/4', 3/8' and 1/2' drill chuck

Impact Drivers : An impact driver is a power tool designed for driving screws and bolts with high torque by delivering rapid, strong rotational impacts. Unlike regular drills, impact drivers combine rotational force with quick bursts of concussive force (impacts) to loosen or drive fasteners more efficiently. Sizes: 1/4' hexagonal drive with maximum torque capacity of approximately 270 Nm.

Screw Drivers : A screw driver is a hand tool or power tool used to drive (insert) or remove screws. It works by applying rotational force (torque) through its tip, which fits into the screw head. Sizes: 1/4' hexagonal drive with maximum torque capacity of approximately 16 Nm.

Ratchet Wrench : A ratchet wrench is a hand tool used to tighten or loosen nuts and bolts efficiently without having to lift and reposition the tool after each turn. It features a ratcheting mechanism that allows the handle to move back and forth while the socket stays engaged with the fastener. Sizes: 3/8' to 1/2' square drive with maximum torque capacity of approximately 120 Nm.

MH Series Electric Power Operated Hydraulic Crimping tools are available with 230 V as well as 110 V Single Phase power supply. The MH Series Hydraulic Crimping Tools are easy to carry and have compact power pack fitted with lifting handle. The MH Series Hydraulic Crimping Tools are supplied with all Aluminum body Motor for less weight and easy portability. Supplied with hand held slim design light weight crimping head, hexagonal dies, and suitable 2 meters long hydraulic hose. Electric Pumps are designed to develop Max. working Pressure up to 700 Bar. The crimping Head is Slim in design and made from Solid Special Alloy Steel to withstand the pressure developed while crimping. Available Models: * SAP-MH-400 – Capacity: 50.0 To 400.0 Sq. Mm (Supplied With Sets Of 9 Sizes Of Dies) * SAP-MH-630 – Capacity: 240.0 To 630.0 Sq. Mm (Supplied With Sets Of 5 Sizes Of Dies) * SAP-MH-1000 – Capacity: 500.0 TO 1000.0 Sq. Mm (Supplied With Sets Of 4 Sizes Of Dies) * SAP-MH-1200 – Capacity: 500.0 To 1200.0 Sq. Mm (Supplied With Sets Of 5 Sizes Of Dies) * Special Model Can Be Supplied With Additional Dies, As Per Customer’s Need. * Extra Long Hose Can Be Supplied With Tool On Request, At Extra Cost. Technical Specifications: Power Supply: 230 Volts Or 110 Volts Single Phase Tank Capacity: 10 Liters Max Working Pressure: 700 Kg/Sq.Cm Motor: 1 HP Pump: 2 LPM For special applications, with high power crimping, we have our HDX and HDZ series Crimping heads, which can be used with both Hand pump as well as Electric pumps, developing up to Max.Working pressure of 700 Bar.

SAPSONS ‘FT’ Series Foot operated Hydraulic Crimping Tools are one of our Unique design, supplied with Heavy duty Foot operated Pump - with sturdiest design, fitted over Heavy steel frame, for well-balanced operation. These are suitable for crimping Copper and Aluminium Cable terminal ends and in-line Connectors upto 1200 Sq.mm. Our FT Series Hydraulic Crimping Tools are equipped with in-built Safety release valve, to prevent the overloading, thus protecting both Pump & Crimping Head. Available Models: * SAP-FT-400 – Capacity: 50.0 To 400.0 Sq. Mm (Supplied With Set Of 9 Sizes Of Dies) * SAP-FT-630 – Capacity: 240.0 To 630.0 Sq. Mm (Supplied With Set Of 5 Sizes Of Dies) * SAP-FT-1000 – Capacity: 500.0 To 1000.0 Sq. Mm (Supplied With Set Of 4 Sizes Of Dies) * SAP-FT-1200 – Capacity: 500.0 To 1200.0 Sq. Mm (Supplied With Set Of 5 Sizes Of Dies) * Special Model Can Be Supplied With Additional Dies, As Per Customer’s Need. * Extra Long Hose Can Be Supplied With Tool On Request, At Extra Cost. The FT Series Hydraulic Crimping Tools that we provide are suitable for any heavy duty crimping applications, to be done at ground positions. Hydraulic crimping head is slim in Design, suitable for easy accessibility inside the panels and confined areas, where other tools cannot be used. Available Models: * SAP-FT-400 – Capacity: 50.0 To 400.0 Sq. Mm (Supplied With Set Of 9 Sizes Of Dies) * SAP-FT-630 – Capacity: 240.0 To 630.0 Sq. Mm (Supplied With Set Of 5 Sizes Of Dies) * SAP-FT-1000 – Capacity: 500.0 To 1000.0 Sq. Mm (Supplied With Set Of 4 Sizes Of Dies) * SAP-FT-1200 – Capacity: 500.0 To 1200.0 Sq. Mm (Supplied With Set Of 5 Sizes Of Dies) * Special Model Can Be Supplied With Additional Dies, As Per Customer’s Need. * Extra Long Hose Can Be Supplied With Tool On Request, At Extra Cost.

SAPSONS ‘HD’ Series Hydraulic Crimping Tools is designed for crimping with Ring or Hex dies to crimp Copper / Aluminium Cable terminal ends/ Ferrules upto 1200 Sq. mm, powered by Heavy duty powerful Hand Pump. The Crimping Head and Hydraulic Hand Pump is connected with 2 Mtr. long Hydraulic Hose pipe and the Hydraulic Hand pump is designed to develop Pressure from 300 to 700 Bar. The crimping Head is Slim in design and made from Solid Special Alloy Steel to withstand the pressure developed while crimping. The mechanism within the pump controls the pressure developed, while crimping and safety valve prevents overloading. This Slim type Hand held Hydraulic crimping head is suitable for Heavy duty crimping and can be easily used inside the panels, very confined areas, critical positions and very critical applications. Available Models: * SAP-HD-400 – Capacity: 50.0 To 400.0 Sq. Mm (Supplied With Sets Of 9 Sizes Of Dies) * SAP-HD-630 – Capacity: 240.0 To 630.0 Sq. Mm (Supplied With Sets Of 5 Sizes Of Dies) * SAP-HD-1000 – Capacity: 500.0 To 1000.0 Sq. Mm (Supplied With Sets Of 4 Sizes Of Dies) * SAP-HD-1200 – Capacity: 500.0 To 1200.0 Sq. Mm (Supplied With Sets Of 5 Sizes Of Dies) * Special Model Can Be Supplied With Additional Dies, As Per Customer’s Need. * Extra Long Hose Can Be Supplied With Tool On Request, At Extra Cost.

Inserting the tubes in to the Tube sheet and Baffle plates is one of the very important activity , in manufacturing of Heat Exchangers, Condensers , Chiller etc., during which the tube ends often get damaged, result into the rejection of complete tubes , most of the time, particularly in Non-Ferrous tubes. Our Tube Guides are designed to protect the tube ends and simplifying the tube insertion process. The Conical shape of the nose allows the Tube end to self align it to the holes in the baffles plates and the tube sheet. Made out of Aluminium nose with Nylon bristle tails, which hold the Guide into the tube ID ., firmly, while insertion. It can be re-used. Sizes Available For ½” To 2.1/2” OD Tubes.
